Your Rust service works on your laptop. Another team needs to run it on a different machine, discover its jobs, configure its keys, observe its health, and recover when the first release is wrong. That is the point where “the binary starts” stops being a deployment plan.
This guide follows the path from a local service to a job run by a Tangle service provider. It focuses on the boundaries a service provider and a consumer can inspect: the job contract, the artifact, the runner, the network settings, the first test-network run, and the return path after failure.
On Tangle, a Blueprint is a reusable definition of software that can run as a service. It describes the executable artifact, the jobs it exposes, the inputs and outputs those jobs accept, and the information needed to operate it. A Service is one live configured instance of a Blueprint. A Job is one callable unit of work inside that Service. An operator is the person or team that supplies the machine, runs the service, responds to jobs, and keeps the instance available.
The public Blueprint introduction describes those three objects and the roles around them.
The Blueprint SDK is Tangle’s Rust toolkit for building, testing, and running those services.
The public Blueprint SDK documentation describes its Rust toolkit, cargo-tangle, the Blueprint Runner (the process that connects job triggers, handlers, and results), the Blueprint Manager (the long-lived operator process that watches chain events and runs services), and optional Hypertext Transfer Protocol (HTTP) gateways.
CLI means command-line interface, the terminal program used to create and operate a Blueprint project.
The companion How Blueprints Work article explains the service lifecycle in broader terms.
The Blueprint Protocol guide focuses on the operator-facing contract and evidence that a service should publish.
Decide what the operator is agreeing to run
Start with one job rather than with a product name.
Imagine a document-labeling service with a job called classify.
The caller supplies a document reference and a language hint.
The job returns labels, confidence values, the model version, and a request identifier.
That sentence is already a deployment contract. It raises questions that project instructions can leave vague:
- Which document formats are accepted?
- What is the maximum input size?
- Is a Uniform Resource Locator (URL) fetched by the operator, and which hosts are allowed?
- What happens when the document is malformed or unavailable?
- How long may the job run?
- Does a rejected request cost anything?
- Which output fields are stable enough for a consumer to depend on?
- Which version of the service produced the result?
Write those answers into the public service definition and run instructions. If an operator must know a setting to start the service, that setting belongs in the deployment contract rather than in a private handoff message.
An illustrative job contract might look like this. It describes the application boundary and is not a claim about a fixed Tangle metadata schema.
{
"name": "classify",
"input": {
"documentUrl": "https://www.w3.org/WAI/ER/tests/xhtml/testfiles/resources/pdf/dummy.pdf",
"language": "en"
},
"output": {
"labels": ["invoice"],
"confidence": [0.94],
"modelVersion": "classifier-2026-06"
},
"errors": [
"invalid_input",
"fetch_denied",
"job_timeout",
"internal_failure"
]
}The contract should state whether the example URL is fetched in the operator runtime or by the caller. That decision changes the network policy, the privacy boundary, the timeout, and the evidence a reviewer should retain.
Create a project that has a runner boundary
The Tangle CLI quickstart documents creating a Blueprint project with:
cargo tangle blueprint create --name document-labelerThe public Blueprint Runner guide describes the runner as the primary process of a Blueprint. The generated project separates job definitions and core logic from the binary that starts the runner.
The runner has several responsibilities.
| Runner part | Plain-language job |
|---|---|
| Entry point | Starts the service process and its configuration |
| Job definition | Describes the callable work and its input and output types |
| Job router | Maps a job identifier to the handler that executes it |
| Producer | Turns an event or request into a job call |
| Consumer | Handles the result after the job finishes |
| Background service | Keeps supporting processes such as an HTTP server or database connection alive |
A job router is easy to misunderstand as a network router. Here it is an in-process dispatch table: a job identifier arrives, and the job router selects the corresponding handler. The job router does not prove that the handler’s result is correct. It only connects the job call to the code that is meant to handle it.
The Blueprint SDK source repository contains the SDK, runner, CLI, examples, and operator documentation. Use its current project template and versioned documentation when you compile a new service because command flags and crate names can change.
Prove the local path before adding a network
The local loop should produce evidence for both success and failure. Start from a clean checkout and run the language-level checks before using a Tangle network.
cargo testThen exercise one valid and one invalid classify request through the same runner route that an operator will use.
The local test should show the input validation, the handler result, the error code, and the process behavior after the error.
Use a small test matrix.
| Test | Expected observation | Why an operator cares |
|---|---|---|
| Valid input | Typed result with request identifier | The happy path is visible |
| Missing required field | Stable input error and no partial result | Bad callers cannot wedge the service |
| Unreachable document | Bounded failure and useful log context | External fetches have a return path |
| Long-running request | Timeout or cancellation is explicit | One job cannot occupy the process forever |
| Two concurrent jobs | Results remain associated with the right request | Shared state is not leaking across jobs |
| Process restart | Service returns to a known state | An operator can recover without manual repair |
A passing local test does not prove that an independent operator can run the service. The local machine may have a cached dependency, an open port, a hidden environment variable, or a credential that the published runbook never mentions.
The Cargo command reference covers the Rust build and test commands. The language tooling checks the application. The Blueprint test flow checks how the application joins Tangle’s service lifecycle.
Make the artifact identifiable
An operator needs three answers before starting a release.
- What artifact am I running?
- Which source and build produced it?
- How can I tell that the artifact I downloaded is the reviewed one?
The artifact may be a native binary, a container image, a WebAssembly module, or another package supported by the deployment path. Publish the source revision, application version, dependency lock state, build target, and integrity value together.
An integrity value is a fingerprint that changes when the artifact changes. For a container, the immutable image digest is more precise than a mutable tag. The Docker image reference documents image identity and commands for inspecting it.
For a Rust service, keep the lockfile in the deployable project when reproducibility matters. The Cargo lockfile guide explains the difference between the manifest that declares dependencies and the lockfile that records the resolved versions.
The source repository, build artifact, and running service are separate boundaries. A source change does not become a deployable release until an artifact is built, identified, and tested. An artifact does not become a healthy service until an operator starts it and a consumer can call it.
Exercise the operator path with a local Tangle network
The Blueprint SDK publishes a local testing flow that uses a seeded Anvil network. Anvil is Foundry’s local Ethereum development node. The Tangle test guide says the local test setup starts Tangle Protocol contracts with pre-seeded state so Blueprint Manager flows can be tested without depending on a public network. An RPC endpoint, or remote procedure call endpoint, is the network address through which the manager communicates with an EVM node. EVM means Ethereum Virtual Machine, the execution environment used by Ethereum-compatible networks.
The documented prerequisites are Rust, Foundry’s anvil, and Docker.
Create a local operator keystore, a protected directory or service that holds signing key material, with the public CLI command:
cargo tangle key --algo ecdsa --keystore ./local-operator-keys --name anvil-operator
export BLUEPRINT_KEYSTORE_URI="$(pwd)/local-operator-keys"The test guide shows the manager configuration for a local Tangle EVM run:
cargo tangle blueprint run \
--protocol tangle-evm \
--http-rpc-url http://127.0.0.1:8545 \
--ws-rpc-url ws://127.0.0.1:8546 \
--keystore-path ./local-operator-keys \
--settings-file ./settings.envThe command is a public example from the Testing with Tangle guide. Use the current SDK runbook for the exact fixture and settings file expected by the version you install.
The local network run should answer two questions: did the process start, and did the job route work?
| Check | Evidence |
|---|---|
| Registration | The Blueprint can be discovered in the local protocol state |
| Startup | The manager starts the service with the published settings |
| Routing | A known job identifier reaches the expected handler |
| Result | The job returns the documented output or error |
| Observation | Logs include service, job, and failure context |
| Restart | The service can be stopped and started without corrupting state |
This is the cheapest place to catch a wrong job identifier, missing setting, bad RPC URL, or incompatible artifact. Fix those issues before asking a public operator to diagnose them.
Publish the operator configuration surface
The current Blueprint SDK documentation lists a common Tangle EVM configuration surface. It includes the HTTP and WebSocket RPC URLs, the core Tangle contract, the staking contract, an optional status registry contract, and the keystore path.
Write each value’s purpose and ownership into the runbook.
| Setting | Meaning | Owner or risk |
|---|---|---|
http_rpc_url | HTTP endpoint for EVM requests | Network availability and rate limits |
ws_rpc_url | WebSocket endpoint for subscriptions | Event delivery and reconnect behavior |
tangle_contract | Core protocol contract address | Wrong address can target the wrong deployment |
staking_contract | Staking and delegation contract address | Network and security configuration |
status_registry_contract | Optional heartbeat and status registry | Liveness reporting and monitoring |
keystore_path | Location of operator signing material | Key protection and filesystem permissions |
Do not publish secret values in the Blueprint metadata. Document how an operator supplies them, how they rotate them, and what happens when a key is unavailable. Separate developer keys, test keys, operator keys, and consumer keys.
The runtime is the environment in which the manager and service processes execute, including the host, container or virtual machine, filesystem, network policy, and resource limits. An operator runbook should state which parts are required by the Blueprint and which parts are a local implementation choice.
Run the first test-network evidence pass
A testnet is a blockchain network used to exercise a service before production. Testnet is the first place where the artifact, operator, service lifecycle, network, and job behavior meet. It should leave an evidence record that a reviewer can understand without relying on a successful local process.
Record the following.
| Testnet question | Record |
|---|---|
| Can an operator discover the Blueprint? | Network, Blueprint identifier, metadata, and job list |
| Can an operator start the service? | Artifact version, settings source, manager version, and startup logs |
| Can a consumer request work? | Service identifier, job identifier, input class, and request result |
| Does a valid job finish? | Output, elapsed time, and transaction or receipt reference when applicable |
| Does an invalid job fail safely? | Error code, timeout behavior, and service state afterward |
| Can a reviewer inspect health? | Heartbeat or status record, health endpoint, and alert owner |
| Can the release be identified? | Source version, artifact fingerprint, and deployment timestamp |
A trace is the ordered record of an execution, including inputs, job calls, outputs, errors, and timing. An evaluation is a repeatable check against a stated expectation, such as a valid result, an error code, or a health response. Keep the trace and evaluation result with the artifact identity so a reviewer can distinguish a service that ran from a service that passed the intended check.
An operator’s heartbeat is a liveness signal. It can show that an operator is reporting status within the expected rules. It does not prove that every job result is correct. The operator introduction describes operator responsibilities such as running services, submitting heartbeats, responding to jobs, and maintaining uptime.
Decide how payment and evidence relate
Payment is part of the deployment contract when the service charges for creation, a subscription, a quote, or each job.
Tangle’s public pricing and payments documentation describes PayOnce, Subscription, and EventDriven pricing models and distinguishes on-chain collection from optional x402 settlement.
x402 is an open payment standard built around Hypertext Transfer Protocol (HTTP) 402 Payment Required.
The server returns payment requirements, the client prepares and authorizes a payment payload, and the server verifies and settles it before returning the resource.
A facilitator is the service that verifies and settles an x402 payment on behalf of the server.
A JobCall is the runner’s internal representation of one job request.
The Blueprint SDK x402 guide documents an optional gateway that advertises job payment requirements, verifies payments through a facilitator, and turns a paid request into a JobCall for the runner.
x402 is separate from the on-chain job submission path. Treat the following as separate checks:
- Did the service communicate the correct payment requirement?
- Did the client authorize the requested payment?
- Did verification or settlement succeed?
- Did the requested job run and return the expected result?
A paid request can settle while the job fails. The production contract needs an explicit policy for retries, refunds, or support when that happens. Payment acceptance is not evidence of output correctness.
Add confidential execution only when the claim needs it
Some services need stronger claims about where code and data ran.
A trusted execution environment (TEE) is a protected execution area designed to isolate code and data from the surrounding host.
An attestation is a signed statement from trusted hardware or an attestation verifier about the software and environment it observed.
An attestation verifier is the software or service that checks that signed statement against the expected identity and policy.
On Tangle, a service can declare a confidentiality policy such as tee_required, which requires TEE placement and stops instead of falling back when the operator cannot satisfy it.
The public execution confidentiality guide documents this policy boundary, and the service API reference documents the request field.
Attestation can support a statement such as “this operator bound the service to the declared protected execution profile.” It does not prove that the model answered correctly, that the application handled every input safely, or that the operator’s surrounding system has no vulnerabilities. Keep the attestation claim beside its assumptions and expiration rules.
If the Blueprint runs an AI agent, an agent profile is the saved configuration for the model, tools, permissions, instructions, and budget used by a run. The profile is application input. The runtime and any attestation are execution-boundary evidence. The result still needs an application evaluation.
Make rollback a tested operation
Promotion means moving a reviewed artifact and configuration from one environment to another. The useful readiness question is whether the team can return to a known working version after an unhealthy release.
Keep the previous artifact and its configuration available until the new release has passed its observation period. Record which operator owns the rollback, which command or deployment action performs it, and which health or job check confirms recovery.
A rollback plan should distinguish several cases.
| Failure | First action | Evidence of recovery |
|---|---|---|
| Process will not start | Restore prior artifact or settings | Manager reaches ready state |
| Job returns invalid output | Stop new traffic and inspect result evidence | Known sample job passes with prior version |
| RPC or event stream fails | Switch to documented endpoint or pause intake | Subscriptions and test job recover |
| Payment accepted, job failed | Apply the documented refund or support rule | Payment and job records reconcile |
| Secret compromised | Revoke and rotate the affected key | New key works and old key is unusable |
| Operator capacity is exhausted | Reduce intake or add an approved operator | Queue and latency return to limits |
Test one rollback before production. A runbook that has never been executed is a hypothesis about recovery.
Keep the release boundary visible
The SDK source, the CLI package, the service artifact, the operator manager, the protocol contracts, and the deployed instance can change at different times. Record their versions separately.
Do not describe a source change as a released CLI feature until the installable package contains it. Do not describe a healthy local test as a production deployment. Do not describe an operator heartbeat as proof that a model or classifier returned a correct result. Do not describe an attestation as a complete security review.
The public Blueprint SDK repository is the implementation source. The Blueprint examples show current example layouts. The Tangle documentation supplies the current network, operator, and CLI guidance. Check those sources again when you pin a version or write an operator runbook.
The practical deployment decision
Use the Blueprint SDK when several operators need to run a common service and consumers need a consistent way to discover the service, create an instance, call a job, and inspect lifecycle evidence. Keep a normal private service when one team owns the full runtime and does not need protocol-level operator coordination.
Before publishing, require one clean local run, one seeded-network run, one testnet job, one intentional failure, and one rehearsed rollback. Record the artifact fingerprint, network, Blueprint and Service identifiers, operator and manager versions, job result, failure behavior, monitoring owner, and payment policy.
The next useful deployment is the smallest isolated testnet job that produces those records. Promotion can wait until the return path works.
What is a Blueprint in Tangle?
A Blueprint is a reusable definition of software that can run as a service. It describes its jobs, inputs, outputs, artifacts, triggers, and optional protocol rules.
What is a Service?
A Service is one live configured instance of a Blueprint with an owner, operators, settings, payment terms, and lifecycle state.
What does an operator do?
An operator supplies infrastructure, runs the Blueprint Manager and service artifact, receives jobs, returns results, reports health, and follows the service runbook.
What does the Blueprint Runner do?
The runner connects job handlers to event producers, result consumers, background services, and the protocol-specific runtime.
Does a testnet deployment prove production readiness?
No. It proves that the defined path ran under the testnet conditions you recorded. Production still needs artifact approval, key management, monitoring, payment handling, security review, and rollback evidence.
Does x402 replace Tangle’s on-chain payment path?
No. x402 is an optional HTTP payment path for paid requests. The on-chain pricing and service lifecycle paths remain separate choices.
What does attestation prove?
Attestation supports a claim about the code or environment observed by trusted hardware or its verifier. It does not prove arbitrary output correctness or remove every trust assumption.
